IMPORTANT: This product page is under construction or the product has reached its End of Life (EOL),
please contact Ringdale for current or alternative product choices.
|
| |
AC - Wiegand to HID USB Converter (Type B Socket)
Wiegand Interface to HID USB converter with Type-B connector
This device converts any numeric Wiegand Data string into HID compatible output. Ideal for a large variety of Wiegand compatible readers that need to be attached to a Ringdale Access Control System or a Laptop.
The unit supports 26-bit to 37-bit Wiegand readers.
The supply voltage for the reader is selectable between 5 volts and 12 volts. Many Wiegand compatible readers require more than 5 volts to operate reliably. Those devices can be solely powered from the converter which has a built-in 12V power supply for the Wiegand reader, as long as the reader's power requirements are within the devices specification.
With this capability the device has been tested to work with a number of Wiegand reader devices:
- Keri
- Mi-Fare
- HID (small reader)
Larger readers will require their own power supply (see wiring instructions of the reader and the HID USB Converter).
|
Caution! All specifications published herein are subject to change without notice. See website for Terms and Conditions of use of the website and the information provided herein. See Ringdale website on www.ringdale.com for Terms and Condtions of Sale and Service. |
